Acer Projector - MEETING ROOMS AND ESSENTIAL | X1228i
Ref.
MR.JTV11.005
Acer Projector - MEETING ROOMS AND ESSENTIAL | X1228i
Ref.
MR.JTV11.005
MID RANGE / SMB SOHO PROJECTORS - MEETING ROOMS AND ESSENTIAL
Features
Loading...
Please note that the 'Features' tab contains general information about the product series. For the exact technical specifications of the selected model, please on the 'Specifications' tab.
Details
Loading...
Specifications
Loading...
▶ Technical Information |
|
|---|---|
Projection Method |
|
Platform Supported |
|
Video Compatibility |
|
▶ Projection Lens |
|
Lens Type |
|
Minimum Focal Length |
21.85 mm |
Maximum Focal Length |
24.01 mm |
Minimum Diagonal Image Size |
584.20 mm |
Maximum Diagonal Image Size |
300" (762cm) |
Minimum Projection Distance |
1 m |
Maximum Projection Distance |
11.80 m |
Optical Zoom |
1.1x |
Lens Shift |
N/A |
▶ Lamp |
|
Lamp Type |
E20.7 |
Number of Lamps |
1 |
Lamp Power |
220 W |
Normal Mode Lamp Life |
6000 Hour |
Economy Mode Lamp Life |
10000 Hour |
ExtremeEco Mode Lamp Life |
15000 Hour |
▶ Image |
|
Maximum Vertical Sync |
120 Hz |
Minimum Vertical Sync |
24 Hz |
Maximum Horizontal Sync |
100 kHz |
Minimum Horizontal Sync |
15 kHz |
Color Supported |
1.07 Billion Colors (30-bit) |
Maximum Resolution |
1920 x 1200 |
Native Resolution |
1024 x 768 |
Native Aspect Ratio |
4:3 |
Compatible Aspect Ratio |
16:9 |
Contrast Ratio |
20,000:1 |
Throw Ratio |
1.94 to 2.16 (1295.40 mm@2000 mm) |
Vertical Keystone Correction |
-40°/+40° |
Standard Mode Brightness |
4800 lm |
Low Mode Brightness |
3,200 ANSI Lumens (ECO) |
Digital Zoom |
2x |
▶ Video |
|
Video Signal Standard |
HDTV |
▶ Multimedia Features |
|
Multimedia Playback |
N/A |
▶ Supported Multimedia Formats |
|
Video Formats |
MPEG-4 ASP, H.264, MPEG-1, VC-1, Xvid, up to 1080p@30fps |
Audio Formats |
MP3, WMA, AAC, WAV, PCM |
Image Formats |
JPEG, BMP |
▶ Audio |
|
Speakers |
Yes |
Number of Speakers |
1 |
Output Power |
3 W |
Speaker Output Mode |
Mono |
▶ Network & Communication |
|
Ethernet (LAN) Capability |
N/A |
▶ Interfaces/Ports |
|
HDMI |
Yes |
USB |
Yes |
VGA In |
Yes |
Audio Line In |
Yes |
Audio Line Out |
Yes |
Number of HDMI Ports |
1 |
Composite Video |
Yes |
▶ Power Description |
|
Power Supply |
AC input 100~240V, 50/60 Hz |
Operating Power Consumption |
260Watts (Standard), 205 Watts (ECO), |
Standby Power Consumption |
<0.5 Watts (Standby) |
▶ Physical Characteristics |
|
Height |
4.5 mm |
Depth |
9.4 mm |
Weight (Approximate) |
2.75 kg |
▶ Miscellaneous |
|
Package Contents |
|
▶ Warranty |
|
Warranty |
2 YEARS (Lamp 1yr or 1K Hours) |
